2020 Husqvarna TC 250 and TC 125 Preview & Specs

For 2020, Husqvarna has slightly revised its popular two-stroke models – the TC 250 and TC 125.

Following are the highlights of the 2020 Husqvarna TC 250 and TC 125 motocross lineup. Specs and availability were not reported as of this writing.

2020 Husqvarna TC 250 specs1. The bodywork was updated on the 2020 TC 250 and TC 125, not just aesthetically but to also improve ergonomics. Husqvarna says the bodywork was tweaked for increased rider comfort across various riding positions. Also, the contact points to the bike were slimmed, and the seat profile redesigned for further comfort.

2. The 2020 Husqvarna TC 250 and TC 125 use chromoly steel frames that are engineered for precise flex, and a composite carbo-fiber subframe that weighs just over 2.2 pounds.

3. WP XACT suspension is used across the two-stroke TC motocross lineup. Up front is a 48mm split-air fork with a single air-pressure valve for pre-load adjustment on the left, and 30 clicks of damping adjustment on the right. Additionally, the air pump needed to adjust the air pressure in the fork is provided as standard. The forks are paired with 22mm off-set CNC-machined triple clams to reduce vibration. Out back, the Husqvarna TC lineup uses a WP XACT rear shock that is pressured balanced for consistent damping.

2020 Husqvarna TC 125 specs 4. The 2020 TC 250 and TC 125 are further highlighted by:

  • Magura hydraulic clutch system offering perfect action in every condition
  • Brembo brake calipers & high-performance discs combining superior stopping power with great control & confidence
  • Traction & launch control with advanced settings
  • Electric starter for easy starting when time is critical
  • Lightweight Li-ion 2.0 Ah battery
  • ProTaper handlebar
  • Progressive throttle mechanism & ODI grips → adjustable throttle progression & easy grip mounting
  • Laser engraved D.I.D. wheels
  • Gearboxes produced by PANKL

2020 Husqvarna TC 250 (TC 125) Specs

ENGINE

  • Type: Single-cylinder four-stroke
  • Displacement: 249cc (124.8cc)
  • Bore x stroke: 66.4 x 72 mm (54 x 54.5 mm)
  • Compression ratio: 14.4:9 (13.5:1)
  • Fuel System: Mikuni TMX 38 Carburetor
  • Starting: Kickstarter
  • Transmission: 5-speed (6-speed)
  • Clutch: Wet multi-disc DDS clutch w/ Magura hydraulics

CHASSIS

  • Frame: Central double-cradle, 25CrMo4 chromoly steel w/ carbon-fiber subframe
  • Subframe: Carbon Fiber
  • Handlebar: ProTaper handlebar
  • Front suspension; travel: Fully adjustable WP XACT inverted 48mm fork; 12.2 inches
  • Rear Suspension: Linkage-assisted WP XACT shock; 11.8 inches
  • Tires: Dunlop AT81
    • Front tire: 80/100 x 21
    • Rear tire: 100/90 x 19
  • Front brake: 260mm disc
  • Rear brake: 220mm disc

DIMENSIONS and CAPACITIES

  • Wheelbase: 58.5 inches
  • Rake: 26.1 degrees
  • Triple clamp offset: 22mm
  • Seat height: 37.4 inches
  • Ground clearance: 14.8 inches
  • Fuel capacity: 2.1 gallons
  • Curb weight: 212 pounds (193 pounds)
