2017 Honda CB1100 EX Buyer’s Guide | Specs & Price

By
Don Williams
-
2017 Honda CB1100 EX price

2017 Honda CB1100 EX

Returning after a two-year hiatus, the Honda CB1100 Deluxe returns as the CB1100 EX. The CB1000 combines retro elements—an air-cooled motor, 18-inch wheels, and twin shocks—with the modern performance we expect.

Certainly, the 1140cc inline-4 has nothing to apologize for when it comes to performance. Not only does it look good, but it’s a muscular engine that always has power on tap.

2017 Honda CB1100 EX price

With the six-speed transmission, you always have the right gear ratio for the task at hand. Handling is outstanding, with a focus on stability—27 degrees of rake and a 58.7-inch wheelbase sees to that.

The seating position is magic, and takes you back to the original Honda CB750 K1 in all the right ways.

Note: The photos are of the Euro version of the CB1100 EX

Read our Honda CB1100 Review.

Visit our Motorcycle Buyer’s Guide.

2017 Honda CB1100 EX Specs

ENGINE

  • Type: Inline-4

  • Displacement: 1140cc

  • Bore x stroke: 73.5mm x 67.2mm

  • Compression ratio: 9.5:1

  • Valve train: DOHC, 4 vpc

  • Fueling: PGM-FI w/ automatic enrichment circuit and 32mm throttle bodies

  • Ignition: Fully transistorized

  • Cooling: Air

  • Transmission: 6-speed

  • Final drive: 530 O-ring chain

CHASSIS

  • Front suspension: 41mm spring-preload adjustable forks; 4.2 inches of travel

  • Rear suspension: Twin spring-preload adjustable shocks; 4.5 inches of travel

  • Front tire: 110/80 x 18

  • Rear tire: 140/70 x 18

  • Front brakes: 296mm floating discs w/ 4-piston calipers

  • Rear brake: 256mm disc

  • ABS: Standard

DIMENSIONS and CAPACITIES

  • Wheelbase: 58.7 inches

  • Rake: 27.0 degrees

  • Trail: 4.4 inches

  • Seat height: 31.2 inches

  • Fuel capacity: 4.4 gallons

  • Curb weight: 540 pounds

2017 Honda CB1000 EX Color:

  • Candy Red

2017 Honda CB1100 EX Price:

  • $12,199 MSRP

2017 Honda CB1100 EX Photo Gallery
